Oxygen Ozone All-in-one Machine

Oxygen Ozone All-in-one Machine

Product introduction

This series of products take the oxygen generated by the built-in oxygen generator as the gas source,and use the ozone generation technology to generate high concentration ozone.Built in ozone part, oxygen part,heat dissipation part, can be used after connecting to water source and power supply. Stainless steel/honeycomb high pressure quartz discharge tube/enamel tube is used to provide over-voltage and over-voltage protection. All stainless steel shell, durable, anti-corrosion, oxidation resistant.

The cost of installation and operation is far lower than that of bottled or liquefied oxygen, which has been designated by many water treatment companies at home and abroad.

Functional Features

1. Built in oxygen generator: zeolite molecular sieve imported from the US is used as adsorbent, and pressure swing adsorption(PSA) is used to separate oxygen and nitrogen in the air,filter out harmful substances/substances in the air,so as to obtain high concentration oxygen meeting the medical oxygen standard, and the pure oxygen output reaches more than 95%. The oxygen flow  can be adjusted to control the ozone concentration.

2. The ozone output and concentration can be adjusted at will, with the adjustment range of 0-100%. The ozone power supply has a dual protection device, which will automatically give an alarm(audible and visual alarm) in case of circuit failure and illegal operation.

3. High frequency ozone power supply us used to generate ozone by silent discharge,effectively solving noise interference.The discharge uniformity is extremely high,the ozone output is large, and the discharge surface does not generate nitrogen oxides and other harmful pollutants.

4. Minutes/hours/weeks/automatic/manual can be adjusted.Microcomputer/controller timing start the machine for 24 hours.

5. Independent research and development of ozone tube: the most advanced titanium enamel ozone generator tube is adopted (its resistance to electric shock and mechanical shock is far better than that of glass medium and ceramic medium) high pressure honeycomb generator tube,dehydroxylation still tube, etc.

6. It can be customized according to user needs: the ozone and gas water device are designed in an integrated way,and the startup time is adjustable.Ozone online detection and other functions.

7. Intelligent touch screen PLC system: programmable controller and human-machine interface automatic control system can continuously monitor,alarm and protect water temperature,water flow,electrical parameters, air pressure and other parameters to ensure safe and normal operation of the system and realize automatic control according to preset procedures.

Product Parameters
